SureCall Guardian4 Public Safety BDA
Providing Reliable Two-way Radio Coverage During Emergencies.
SureCall’s Guardian4™ Public Safety Band signal booster amplifies FirstNet signals for crucial communications, delivering consistent signal for First Responders and other public safety officials relying on two-way radio communication inside large buildings.
The Guardian4 is a bi-directional amplifier with a maximum gain of 80 dB on the Public Safety frequency bands, supporting 700 MHz (FirstNet Ready) and 800 MHz.
In the majority of cases, newly constructed buildings with considerable size, or existing buildings that increase capacity by expanding the building footprint are required to have signal strength of -95 dBm or better in designated critical areas – elevators, stairwells, etc. – in order to receive a certificate of occupancy. The Guardian4 meets the code for NFPA 1221 and IFC 510 and features a NEMA-4 rated amplifier housing, which eliminates the need for an additional NEMA enclosure.
Additionally, the Guardian4 Public Safety BDA comes equipped with dry contact 7-pin alarming capability, UPS and Ethernet port enabled remote monitoring. The BDA features sturdy metal construction and is covered by an industry leading 3-year warranty.
- Provides improved coverage for Public Safety 700 MHz (FirstNet) and 800 MHz
- 80 dB gain for Public Safety Bands
- Features built-in SureCall Sentry™ remote monitoring with ethernet port
- Integrated 7-pin alarm and UPS port for external battery backup
- Meets the code for NFPA 1221 and IFC 510
- NEMA-4 rated amplifier housing. No additional NEMA enclosure(s) needed
Installation & Deployment
At Signal Boosters we provide full turnkey integration of in-building wireless (IBW) systems that amplify signal indoors, delivering the signal you need to get the job done. From the first call to post-project, Signal Boosters handles every detail personally in-house. Our team of RF engineers, system integrators, designers, and certified signal boost specialists take complete ownership of your project.
- Pre-survey
- Site survey
- Data analysis
- Floor plans
- Equipment & Pricing
- Installing equipment
- Optimization
- Documentation
- Monitoring & support
Tech Specs
| SureCall Guardian4 Public Safety Signal Booster | |
|---|---|
| Frequencies - Uplink | 788-805 MHz; 806-816 MHz |
| Frequencies - Downlink | 758-775 MHz; 851-861 MHz |
| Supported Standards | /surecall-signal-booster-installation/Public Safety 700 (FirstNet), 800 MHz |
| Impedance | 50 Ohm |
| Maximum Gain | 80 decibels (dB) |
| Power Input | A/C 110V or D/C 16-24V power option |
| P1dB | 31.5 dBm |
| Connectors | N-Female |
| Power Consumption | 35W |
| Dimensions | 25 x 19 x 9 inch |
| Weight | 54 lb |
| FCC ID | RSNGUARD-2QR |
FCC NOTICE:
This is NOT a CONSUMER device. It is designed for installation by FCC LICENSES and QUALIFIED INSTALLERS. You MUST have an FCC LICENSE or express consent of an FCC Licensee to operate this device. Unauthorized use may result in significant forfeiture penalties, including penalties in excess of $100,000 for each continuing violation.
WARNING: California's Proposition 65
Support
The SureCall Guardian4 Public Saftey Amplifier can be customized for your specific needs. Contact our dedicated public safety solutions team
(1-800-919-8189 or pro@signalboosters.com) to assist you in every step of the way.
